Description
| Size | DN 350 - 800, NPS 14 -32 |
|---|---|
| Pressure | up to PN160, up to class 900 |
| Body sealing | Self sealing, cover sealing |
| Shaft sealing | Molded graphite packing rings |
| Closure time | < 2 sec. |
| Material | Body: SA217WC6 Shaft: 1.4122 nitriding Disc lever = Hardfacings: 1.4115 Bearing sleeve 1.8550 nitriding Leakage classLeakage rate 2 acc. To DIN3220 pa |
| Leakage class | Leakage rate 2 acc. To DIN3220 part 3 or IEC 534 part 4, Class IV, test course 2, medium L |
| Connection | Welding ends acc. to EN/DIN and ASME |
