Description
| Pressure Registration | External |
|---|---|
| Temperature Capabilities | Nitrile (NBR):?-20 to 180°F / -29 to 82°C | Fluorocarbon (FKM): 20 to 250°F / -7 to 121°C; limited to 200°F / 93°C in hot water | Ethylene Propylene (EPDM): -20 to 225°F / -29 to 107°C |
| Body Sizes | NPS 1 / 2 / 3 / 4 | DN 25 / 50 / 80 / 100 |
| End Connections | NPT / CL125FF / CL150RF / CL250RF / CL300RF / CL600RF / PN 16/25/40 |
| Maximum Inlet Pressure | 400 psig / 27.6 bar | Or body rating limit, whichever is lower |
| Maximum Outlet Pressure | 400 psig / 27.6 bar | Or body rating limit, whichever is lower |
| Spring Ranges | 5 to 300 psig / 0.4 to 20.7 bar |
| Additional Technical Data | For additional technical information,?contact?your local?Sales Office?or refer to technical documentation. |
