Description
| Body Sizes | 3/4 or 1-inch / DN 20 or 25 |
|---|---|
| Maximum Allowable Inlet (Casing) Pressure | Gray Cast Iron: 35 psig / 2.4 bar WCC Carbon Steel, LCC Carbon Steel or CF8M/CF3M Stainless Steel: 75 psig / 5.2 bar |
| Maximum Outlet Pressure | 35 psig / 2.4 bar |
| Max Emergency Inlet Pressure to Avoid Internal Parts Damage | NBR or FKM diaphragm: 35 psig / 2.4 bar FEP diaphragm: 10 psig / 0.7 bar |
| Standard Temperature Capabilities | NBR: -20 to 180°F / -29 to 82°C FEP: -20 to 180°F / -29 to 82°C EPDM: -20 to 225°F / -29 to 107°C |
| High Temperature Capbailities | FKM: 40 to 300°F / 4 to 149°C FFKM: 0 to 300°F / -18 to 149°C |
| Spring Case Vent Connection | 1/4 NPT |
| Diaphragm Case Control Line Connection (Type T208M) | 1/2 NPT |
| Approximate Weight | 17.7 pounds / 8 kg |
| Additional Technical Data | For additional technical information, contact your local Sales Office or refer to technical documentation. |
